VERTICAL LATHE WITH 1600MM HEIGHT DVT5120
$60000
|
Specification |
Unit |
DVT5120 |
|
Max Cutting Diameter |
mm |
2000 |
|
Table Diameter |
mm |
1800 |
|
Max Workpiece Height |
mm |
1600 |
|
Max Workpiece Weight |
t |
8 |
|
Max Torque of Table |
KN.m |
40 |
|
Table Rotation Speed Range |
r/min |
1-100 |
|
Max Cutting Force of Vertical Holder |
KN |
22 |
|
Tool Rest Feed Range |
mm/min |
0.1-500 |
|
Tool Rest Feed Steps (Stepless) |
Step |
Variable |
|
Horizontal Travel of Rail Head |
mm |
1050 |
|
Ram Travel of Rail Head |
mm |
800 |
|
Crossbeam Travel |
mm |
900 |
|
Fast Moving Speed of Tool Heads |
mm/min |
630 |
|
Beam Lift Speed |
mm/min |
0.8-86 |
|
Knife Rod Cross-Section Size (W×H) |
mm |
30×40 |
|
Main Motor Power |
KW |
30 |
|
Overall Size of Machine (L×W×H) |
mm |
4300×5000×3480 |
|
Weight of Machine |
t |
17.5 |
|
|
|
