CNC Pipe threading lathe with FANUC 0i TF QK1325X1500
$38000
| Item | Unit | QK1325X1500 | |
| Nc System | mm | FANUC 0i TF | |
| Max dia.swing over bed | mm | 800 | |
| Max dia.swing over cross slide | mm | 480 | |
| Max.length of work-piece | mm | 1500 | |
| Width of bed | mm | 600 | |
| Pipe threading range | mm | Φ50-250 | |
| Spindle bore | mm | 255 | |
| Spindle center height | Kw | 400 | |
| Power of spindle motor | 15 | ||
| Mode of spindle speed | Two gears， smooth adjustment | ||
| Range of spindle speed | （L）:15-100 | ||
| r/min | （H）:100-350 | ||
| Max.traverse of X/Z | mm | X:420 Z:1250 | |
| X/Z rapid traverse | mm/min | 4000/6000 | |
| X-axis motor | Speed | r/min | 2000 |
| Torgue | N.m | 22 | |
| Power | Kw | 2 | |
| Z-axis motor | Speed | r/min | 2000 |
| Torgue | N.m | 30 | |
| Power | Kw | 3 | |
| Tailstock quill | Diameter | mm | 120 |
| Travel | mm | 250 | |
| Taper | Morse NO.6 | ||
| Electric tool-post | Model | AK21240 | |
| No.of tool stations | Vertical four-station | ||
| Dimension | mm | 32×32 | |
| Turret indexing time | S | 2.6 | |
| Chuck Ф630(front）Ф630（rear） | Front chuck 4 jaw Rear chuck 4 jaw | ||
| Positioning accuracy | mm | 0.02 | |
| Repositioning accuracy | mm | 0.01 | |
| Overall dimensions(L*W*H) | mm | 4200×2100×1900 | |
| Machine weight | T | 7 | |
